The CreatBot D600Pro was created to make industrial 3D printing of large-scale objects and prototype as easy as possible. It is embedded with many advanced technology for ultra big, impressive, prints. It will be your best choice with no doubt, If you are looking for an lndustrial large scale 3D printer for prototype and engineering-grade materials.
Affordable price plus a build size 600*600*600mm, make it the best choice to your business. Trusted by 2000+ professional clients.
D600 and D600 Pro equiped with the 4th generation 1.75mm dual extruders and hotends. The left extruder equipped with 260°C hotend, It is able to print with PLA, ABS, PC, Nylon, Carbon fiber, Flexible, etc. The right extruder 420°C hotend is made of martensite steel, which is able to print high performance materials. The dual hotend is replaceable, which provide more possibility on your application.
The printer will automatically memorize the current position and save print data. Lower the platform and withdraw filament when power off suddenly. It will continue to print from the last stopped point after power on. No trace!
The printer will avoid invalid printing by stoping print and warning when filament runs out.
When it reachs to 600mm+ length, small rail have big deflection. The D600 Pro accurate linear rail structure is very thick and strong. It won’t deform or loss precision after print head million times shock.
With servo motors, timeliness, fast response, no inertia, no delay. closed-loop control of position overcome the problem of lossing step. heat and noise are significantly reduced. It gives print model ultra high performance with high speed.
70°C hot chamber ensures print quality for high performance materials. The fully enclosed chamber can block all external interference. Also this frame can reduce noises, at the same time to provide constant temperature, so that the model won't deform.
The filament dry room provides chamber temperatures of 45°C and 65°C to dry big roll filament like PLA, nylon, PC, ABS and other materials with water absorption.
Use of 49 points through the high precision servo probe to save the level of platform flatness data at the initial, through the Z axis intelligent compensation table height in the printing process to achieve fully automatic leveling.
The air filter system can adsorb impurities and gases that generated by printing special filament like ABS, Nylon, PC, more safe and environmental protection which is more suitable for house, school, office space.
|Print Technology||Fused Deposition Modeling（FDM）|
|Build Volume||Single Extrusion: 600*600*600 mm
Dual Extrusion: 540*600*600 mm
|Number of Nozzles||Double|
|Layer Resolution||0.05 mm|
|Filament Diameter||1.75 mm|
|Filament Compatibility||PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PETG, HIPS, PP, Flexible, TPU, PVA, etc.|
|Nozzle Diameter||0.4mm (0.3 0.5 0.6 0.8 1.0mm)|
|Print File Type||STL, OBJ, AMF, Gcode|
|Ambient Operating Temperature||15 ℃~32 ℃|
|Max. Nozzle Temperature||420 ℃|
|Max. Bed Temperature||100 ℃|
|Max. Chamber Temperature||70 ℃ D600 Pro|
|Filaments Drying Temperature||45 ℃/65 ℃ D600 Pro|
|Construction||Power-Coated Steel, Aluminum Casting for Motion Components, POM|
|Build Plate||Aviation aluminum plate|
|Build Plate Leveling||Factory Leveled, Adjust Manually Automatic D600 Pro|
|Stepper Motors||1.8° Step Angle with 1/16 Micro-stepping|
|X Y Positioning Precision||5.08 μm|
|Z Positioning Precision||1.25 μm|
|Best Printing speed||45 mm/s|
|Max. Printing speed||120 mm/s|
|200V-240V / 50-60Hz ( D600 / D600 Pro )|
|Screen||4.3'' Touch Screen with Multi-language|
|Rated Power||D600: 1500W, D600 Pro: 4900W|
|Storage Media||USB Disk|
|Software||CreatWare, Simplify 3D, Cura, Slic3r, etc|
|Supported File Types||STL,OBJ,AMF|
|Operating Systems||Win7/8/10, macOS|
|Outage Restored||Save data when power is off|
|Filament Detection||Pause printing when filament run out|
|Automatic Shut-down||Turn off the power automatically when printing is complete|
|Size & Weight|
|Product Dimensions & Weight||915*845*1085mm 125kg|
|Packing Size & Weight||940*1010*1320mm 165kg(Pallet)|
